PNK CRP S15 Carbon vacuum pumps
PNK CRP S15 Carbon vacuum pumps

PNK CRP-S Series of carbon vacuum pumps

Modal: PNK CRP S15 Carbon vacuum pumps

Applied 6P motor with low rotate speed 965r/min

More stable operation, lower noise, longer service life

Huge flow design with gas efficiency up to 1500L/min

Motor power(Single phase):  0.4Kw

Exhaust gas:      280L/min

Extreme vacuum limit:    84kpa

Do you want to know more?

If you need more product documents and data, please contact us directly at CANKER.

Technical parameterUnitFrequencyPNK CRP S15
Rotate speedrmp
1430
Design degassing amountL/min50 Hz280
Extreme vacuumkpa50 Hz84
Normal vacuumkpa
60
Common degassing pressurekpa
60
Pipe connector"
RC3/4
PowerV50 Hz100-220(Single phase)/200-380(Triple phase)
Loading motorKw
0.4/0.37
Weightkg
25

PNK CRP-S15碳片真空泵.png

PNK CRP-S15碳片真空泵.png

PNK CRP S15 Carbon vacuum pumps
